PRINTED CIRCUIT BOARDS

Surface Mount PC Board Line
(1) Panasonic SSP-G1 Screen Printer
(1) Panasonic MV-140 Chip Shooter
(1) Panasonic MPA-3F Flexible Assembler
(1) Panasonic MV-2F Chip Shooter
(1) Panasonic OA-CON XL Open Aisle Conveyor
(2) Panasonic CCON XL Connecting Conveyor
(1) Panasonic ICON XL Inspection Conveyor
(2) Panasonic CCON LL Connecting Conveyor
(1) Panasonic C-CON Connecting Conveyor with Push Arm
(1) Panasonic MBSF Magazine Feeder
(1) Panasonic MBS Magazine Unloader
(1) Panasonic HVA-102 Conceptronics Reflow Oven
(6) Panasonic Magazines
(197) Panasonic MV Feeders
(91) Panasonic MPA Feeders
(3) Panasonic MPA Feeder Racks
(1) Panasonic MPA Feeder Cart
(2) Panasonic MV Feeder Racks
(3) Panasonic MV Feeder Carts
(1) BTU International ADP-1
(1) Reflow Oven

Through Hole PC Board Line
(4) Burn in Ovens
(2) CS-400C Component Locator Machines
(1) Polar Tone Ohm 950 Multilayer Short Locator.
(1) Pace Programmable Thermoflo
(1) Pace HS 200 Heat Wave System
(1) Meji Techno Microscope w/Camera
(1) G.P.D. CF8 Component Former
(1) GTI MM-1uv Minimatcher Color Viewing System
(1) Hollis Future 1 SMT Wave Solder Station w/ Air Knife
(1) Omega Metr Model 600 SMD
(1) Ultra Clean - 2100 Ultrasonic
(1) Solder Pot Air - Vac Model PCBRM-10
(1) Gruenberg Bake Oven

Manufacturing & Q.C. Inspection Tooling
(6) Bausch & Lomb Stereo Zoom 4 Microscopes
(14) Dazor Lamps Model PCBRM-10
(1) Gruenberg Bake Oven
(1) Lynx Dynascope

TEST EQUIPMENT

(1) Tektronic DAS 9100 Digital Analysis System
(1) Tektronic TM 504 Mainframe w/ PG504 Calibration Generator, SG Sine Wave Generator, SG502 Oscillator, TG501 Time Mark Generator
(1) Fluke 761A Universal Counter/Timer
(1) Intel Universal PROM Programmer PG 505 Pulse Generator
(1) HP 8080A Mainframe w/ 8081A Rate Generator, 8084A Worg Generator, 8083 Amplifier
(1) ROD-L M100AVS5 SC Hi-Pot Tester
(1) BP Microsystems UniversalAssorted Tektronic Oscilloscopes and Plugable Modules
Device Programmer BP-1200 with Various Modules

Fabrication and Machining Facilities>
